ZDF2 40W Hypoid Gear Motor Suppliers

Home / Products / ZDF2、ZDF3 Hypoid Gear Motor / ZDF2 Hypoid Gear Motor / ZDF2 40W Hypoid Gear Motor

Model

Output Power

Voltage

Frequency

Rated Current

Rated Torque

Rated Speed

Locked Rotor Torque

Locked Rotor Current

Insulation Grade

W

V

Hz

A

N.m

r/min

N.m

A

ZDF2-15H☐-40-S(TB)

40

200

60

0.27

0.25

1500

0.62

0.76

F

220

50

0.29

0.29

1320

0.90

0.90

ZDF2-15H☐-40-S3(TB)

380

50

0.17

0.29

1320

0.90

0.56

460

60

0.16

0.23

1650

1.00

0.62



Model

Output Power

Voltage

Frequency

Rated Current

Rated Torque

Rated Speed

Locked Rotor Torque

Locked Rotor Current

Capacitor

Insulation Grade

W

V

Hz

A

N.m

r/min

N.m

A

UF

ZDF2-18A☐-40-C(TB)

40

220

60

0.33

0.23

1650

0.20

0.80

2.50

F

220

50

0.33

0.29

1350

0.20

0.85

ZDF2-18A☐-40-A(TB)

110

50

0.65

0.29

1350

0.20

1.70

10.0

110

60

0.65

0.23

1650

0.20

1.50



Power

Aperture/Axis Diameter

ReductionRatio

Output Shaft Speed

Output Shaft Torque

Output Shaft Tolerance

Output Shaft Tolerance

r/min

N.m

kgf.m

Axial Force Load

W

mm

i

50Hz

50Hz

50Hz

N

kgf

N

kgf

40

15/18

10

150

2.350

0.23

343

35

88

9

15

100

3.520

0.35

441

45

108

11

20

75.0

4.690

0.47

539

55

137

14

25

60.0

5.870

0.59

588

60

147

15

30

50.0

7.040

0.71

686

70

177

18

40

37.5

9.390

0.95

784

80

196

20

50

30.0

11.74

1.19

882

90

226

23

60

25.0

14.09

1.43

882

90

226

23

80

18.8

16.91

1.72

980

100

245

25

100

15.0

21.14

2.15

980

100

245

25

120

12.5

25.36

2.58

1080

110

275

28

160

9.40

33.82

3.45

1370

140

343

35

200

7.50

42.28

4.31

1370

140

343

35

240

6.30

50.73

5.17

1370

140

343

35





■ ZDF2-15H10~240-40-C(T)    ZDF2-15H10~240-40-S(T)
ZDF2-15H10~240-40-A(T)     ZDF2-15H10~240-40-S3(T)



Note: Conventional products without wiring box

■ ZDF2-18A10LRT~240LRT-40-C(ТB)    ZDF2-18A10LRT~240LRT -40-A(TB)
ZDF2-18A10LRT ~240LRT-40-S(TB)    ZDF2-18A10LRT~240LRT-40-S3(TB)



Note: Conventional products without wiring box
