60W-90mm DC Worm Gear Right Angle Brush Gear Motor Suppliers

Home / Products / DC Gear Motors / Brush DC Gear Motors / 60W-90mm DC Worm Gear Right Angle Brush Gear Motor

•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank (□) within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 20 N.m.



Type

Motor/Gearhead

Gear Ratio

7.5

9

12.5

15

18

25

30

36

50

60

75

90

100

120

150

180

Speed r/min

373

311

224

186

155

112

93

77

56

46

37

31

28

23

18

15

Z5D60-24GU-28S

5GU□RH

5GU□RA

0.50

0.60

0.83

0.99

1.19

1.66

1.99

2.39

3.32

3.98

4.97

5.97

6.63

7.96

9.95

11.9

5.10

6.12

8.47

10.1

12.1

16.9

20.3

24.4

33.9

40.6

50.7

60.9

67.6

81.2

101

121
