40W-80mm DC Worm Gear Right Angle Brush Gear Motor Suppliers

Home / Products / DC Gear Motors / Brush DC Gear Motors / 40W-80mm DC Worm Gear Right Angle Brush Gear Motor

•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank (□) within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 8 N.m.



Type

Motor/Gearhead

Gear Ratio

7.5

9

12.5

15

18

25

30

36

50

60

75

90

100

120

150

180

Speed r/min

400

333

240

200

166

120

100

83

60

50

40

33

30

25

20

16

Z4D40-24GN-30S

4GN□RH

4GN□RA

0.31

0.37

0.52

0.62

0.74

1.03

1.24

1.49

2.06

2.48

3.09

3.71

4.13

4.95

6.19

7.43

3.16

3.77

5.30

6.32

7.55

10.5

12.6

15.2

21.0

25.3

31.5

37.8

42.1

50.5

63.1

75.8
