90W-90mm DC Spiral Bevel Right Angle Brush Gear Motor Suppliers

Home / Products / DC Gear Motors / Brush DC Gear Motors / 90W-90mm DC Spiral Bevel Right Angle Brush Gear Motor

•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank (□) within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 20 N.m.



Type

Motor/Gearhead

Gear Ratio

7.5

9

12.5

15

18

25

30

36

50

60

75

90

100

120

150

180

Speed r/min

373

311

224

186

155

112

93

77

56

46

37

31

28

23

18

15

Z5D90-24GU-28S

5GU□RC

5GU□RT

1.68

2.01

2.80

3.36

4.03

5.59

6.71

7.25

10.1

12.1

15.1

18.1

20.0

20.0

20.0

20.0

17.1

20.5

28.6

34.3

41.1

57.0

68.4

74.0

103

123

154

185

200

200

200

200
