25W-80mm DC Worm Gear Right Angle Brush Gear Motor Suppliers

Home / Products / DC Gear Motors / Brush DC Gear Motors / 25W-80mm DC Worm Gear Right Angle Brush Gear Motor

•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank (□) within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 8 N.m.



Type

Motor/Gearhead

Gear Ratio

7.5

9

12.5

15

18

25

30

36

50

60

75

90

100

120

150

180

Speed r/min

380

316

228

190

158

114

95

79

57

47

38

31

28

23

19

15

Z4D25-24GN-28.5S

4GN□RH

4GN□RA

0.20

0.24

0.34

0.41

0.49

0.68

0.81

0.98

1.36

1.63

2.04

2.44

2.71

3.26

4.07

4.89

2.04

2.45

3.47

4.18

5.00

6.94

8.26

10.0

13.9

16.6

20.8

24.9

27.6

33.3

41.5

49.9
