•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank (□) within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 8 N.m.
|
Type Motor/Gearhead |
Gear Ratio |
7.5 |
9 |
12.5 |
15 |
18 |
25 |
30 |
36 |
50 |
60 |
75 |
90 |
100 |
120 |
150 |
180 |
|
Speed r/min |
400 |
333 |
240 |
200 |
166 |
120 |
100 |
83 |
60 |
50 |
40 |
33 |
30 |
25 |
20 |
16 |
|
|
Z4D40-24GN-30S |
4GN□RC 4GN□RT |
0.70 |
0.84 |
1.16 |
1.39 |
1.67 |
2.32 |
2.78 |
3.34 |
4.64 |
5.01 |
6.27 |
7.52 |
80.0 |
80.0 |
80.0 |
80.0 |
|
7.14 |
8.57 |
11.8 |
14.2 |
17.0 |
23.7 |
28.4 |
34.1 |
47.3 |
51.1 |
64.0 |
76.7 |
80.0 |
80.0 |
80.0 |
8.00 |
