Our Mission : Zhongda realizes the infinite possibilities in automation applications.
We can provide customized products and project products according to specific requirements. Please feel free to contact us if you need.
•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank (□) within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 20 N.m.
|
Type Motor/Gearhead |
Gear Ratio |
7.5 |
9 |
12.5 |
15 |
18 |
25 |
30 |
36 |
50 |
60 |
75 |
90 |
100 |
120 |
150 |
180 |
|
Speed r/min |
373 |
311 |
224 |
186 |
155 |
112 |
93 |
77 |
56 |
46 |
37 |
31 |
28 |
23 |
18 |
15 |
|
|
Z5D40-24GU-28S |
5GU□RH 5GU□RA |
0.33 |
0.40 |
0.55 |
0.66 |
0.80 |
1.11 |
1.33 |
1.59 |
2.21 |
2.65 |
3.32 |
3.98 |
4.42 |
5.30 |
6.63 |
7.96 |
|
3.37 |
4.08 |
5.61 |
6.73 |
8.16 |
11.3 |
13.6 |
16.2 |
22.5 |
27.0 |
33.9 |
40.6 |
45.1 |
54.1 |
67.6 |
81.2 |
NINGBO ZHONGDA LEADER INTELLIGENT TRANSMISSION CO.,LTD. was established in 2006, we have more than 1500 employees, 66666m2 area and we have got 676 million sales on 2019.
