| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
| U | V | W | GND | Hv | Hw | Hu | +Vcc |
|
Motor Type |
Gearbox Model |
Gear Ratio |
L Dimension (mm) |
|
Z42BLDPN |
42PN□ |
3.65~8.63 |
33.8 |
|
13.53~58.22 |
47.4 |
||
|
67.08~392.98 |
61.0 |
|
Motor Type |
Voltage |
Rated Power |
Rated Current |
Rated Speed RPM |
Rated Torque N.m |
Grade Protection IP |
|
Z42BLDPN2440-30S |
24 |
40 |
2.4 |
3000 |
0.127 |
20 |
|
Ratio |
3.65 |
5.36 |
6.55 |
8.63 |
13.53 |
18.92 |
24.65 |
28.05 |
33.92 |
44.69 |
58.22 |
67.08 |
81.11 |
|
Output shaft speed r/min |
822 |
560 |
458 |
348 |
222 |
159 |
122 |
107 |
88 |
67 |
52 |
45 |
37 |
|
Allowable torque N.m |
0.42 |
0.61 |
0.75 |
0.99 |
1.40 |
1.95 |
2.54 |
2.89 |
3.50 |
4.61 |
6.00 |
6.24 |
7.54 |
|
Reduction stage |
1 |
1 |
1 |
1 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
3 |
3 |
|
Ratio |
91.36 |
102.88 |
118.98 |
127.74 |
145.36 |
165.64 |
191.56 |
231.61 |
301.68 |
392.98 |
|
|
|
|
Output shaft spaed r/min |
33 |
29 |
25 |
23 |
21 |
18 |
16 |
13 |
10 |
8 |
|
|
|
|
Allowable torque N.m |
8.49 |
9.55 |
11.06 |
11.87 |
13.51 |
15.0 |
15.0 |
15.0 |
15.0 |
15.0 |
|
|
|
|
Reduction stage |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
3 |
|
|
|
