120W-90mm DC Worm Gear Right Angle Brush Gear Motor Suppliers

Home / Products / DC Gear Motors / Brush DC Gear Motors / 120W-90mm DC Worm Gear Right Angle Brush Gear Motor

•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank (□) within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 20 N.m.



Type

Motor/Gearhead

Gear Ratio

7.5

9

12.5

15

18

25

30

36

50

60

75

90

100

120

150

180

Speed r/min

346

288

208

173

144

104

86

72

52

43

34

28

26

21

17

14

Z5D120-24GU-26S

5GU□RH

5GU□RA

1.07

1.29

1.79

2.14

2.57

3.57

4.28

5.14

7.14

8.57

10.7

12.9

14.3

17.1

20.0

20.0

10.9

13.2

18.3

21.8

26.2

36.4

43.7

52.4

72.8

87.4

109

132

146

174

200

200
