Basic parameter |
||||||||
| Model |
Power |
Voltage |
Frequency |
Current |
Speed |
Work duty |
Protection grade |
Insulation class |
|
ZD-750W-S16V |
0.75kW |
16V |
90Hz |
41A |
2560r/min |
S2-60min |
IP 42 |
F |
|
Other parameter |
||||||
|
Reducer type |
Reduction ratio |
Brake voltage |
Brake torque |
Ambient temperature |
Noise |
Connection |
|
NL24.68KL |
24.685K/17K |
48V DC |
8.0N.m |
-10℃~+40℃ |
<65dB (L=100cm) |
|
|
Black AMP 4-port terminal block connection |
|||
|
① |
② |
③ |
④ |
|
VCC（YEL） |
OUT A（WHT） |
OUT （BLU） |
GND（BLK） |
|
Speed detection |
|||
|
Encoder: 32 bites |
|||
|
Black AMP 2-port terminal block connection |
|
|
① |
② |
|
Sensor （+）（RED） |
Sensor （-）（BLU） |
|
Speed detection |
|
|
Sensor type：KTY84-150 (PHILIPS) |
|
